Cub Cadet 3165
1998 - 1999 3000 Series Garden tractor
Series map:
3165
3185
16.0hp
18.0hp
Production Manufacturer Cub Cadet (a part of MTD)
Garden tractor Original price $5,000 (1998 )
$5,100 (1999 )
Mechanical Two-wheel drive Power steering Disc brakes Open operator station.
Tractor hitch Rear Type 0 Opt Optional
Power Take-off (PTO) Front PTO independent
Clutch electro-pneumatic idler
Front PTO Type shaft (SAE BB)
3165 Serial Numbers Location: Serial number decal on the left side of the frame, above the front axle.
Electrical Ground negative
Charging system flywheel alternator
Charging amps 16
Battery CCA 435
Battery volts 12
References Series 3000 Garden Tractors published in 1997, by Cub Cadet Series 3000 Garden Tractors published in 1998, by Cub Cadet 3000 Series Service Manual (770-10227) published in 1999 1998 Dealer Sales Manual published by Cub Cadet
Page information Copyright 2025 TractorData.com® Email me: Peter@TractorData.com TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. Peter Easterlund - owner/authorThis machine's data modified on September 19, 2025
©2000-2025 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
