Ingersoll 3016


Ingersoll 3016 lawn tractor photo
1989 - 2004
3000 Series
Garden tractor
Series map:
3014
3016
3018
14.0hp
16.0hp
18.0hp
Production
ManufacturerIngersoll
Garden tractor
Built in Winneconne, Wisconsin, USA
Ingersoll 3016 Engines
16HP Onan 709cc 2-cyl gasoline
16HP Briggs & Stratton 480cc 2-cyl gasoline
Fuel tank3 gal
11.4 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Hydraulics
Typeopen center
Pressure2100 psi (transmission)
144.8 bar
 575 psi (lift)
39.6 bar
Valves2
Pump flow8 gpm
30.3 lpm
Tractor hitch
Rear Type0 OptOptional
Dimensions & Tires
Wheelbase46 inches
116 cm
Weight683 lbs
309 kg
Front tire16.50-8
Rear tire23x10.50-12
Full dimensions and tires ...
Ingersoll 3016 attachments
42" mid-mount mower deck
44" mid-mount mower deck
48" mid-mount mower deck
snowblower
blade
Attachment details ...
3016 Serial Numbers
3016 Serial Location
Ingersoll 3016 serial number location
Serial number on the left side of the tractor frame, above the footrest.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps20
Charging volts12
Battery CCA300
Battery volts12
References
3016 references literature
Compact Tractors 3012, 3014, 3016, 3018, 3018PS, 4016, 4020, 4020PS (8-59130) published in 1993
