Ingersoll 3018


Ingersoll 3018 lawn tractor photo
1989 - 2004
3000 Series
Garden tractor
Series map:
3016
3018
16.0hp
18.0hp
Production
ManufacturerIngersoll
Garden tractor
Built in Winneconne, Wisconsin, USA
Variants
3018PSpower steering
Ingersoll 3018 Engines
18HP Onan 781cc 2-cyl gasoline
18HP Briggs & Stratton 569cc 2-cyl gasoline
Fuel tank3 gal
11.4 L
Engine details ...
Mechanical
Two-wheel drive
3018 Steeringmanual
3018PS Steeringpower
Open operator station.
Photos
No photos of the Ingersoll 3018 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2100 psi (transmission)
144.8 bar
 575 psi (lift)
39.6 bar
Valves2
3018 Pump flow8 gpm
30.3 lpm
3018PS Pump flow9.5 gpm
36.0 lpm
Tractor hitch
Rear Type0 OptOptional
Dimensions & Tires
Wheelbase46 inches
116 cm
Weight683 to 725 pounds
Front tire16.50-8
Rear tire23x10.50-12
Full dimensions and tires ...
Ingersoll 3018 attachments
42" mid-mount mower deck
44" mid-mount mower deck
48" mid-mount mower deck
snowblower
blade
Attachment details ...
3018 Serial Numbers
3018 Serial Location
Ingersoll 3018 serial number location
Serial number on the left side of the tractor frame, above the footrest.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps20
Charging volts12
Battery CCA300
Battery volts12
References
3018 references literature
Compact Tractors 3012, 3014, 3016, 3018, 3018PS, 4016, 4020, 4020PS (8-59130) published in 1993
