International Harvester 2544 - engine

International Harvester 2544 industrial tractor photo
Industrial tractor
more International Harvester 2544 specifications...






Engine Detail:

 International Harvester D239
 diesel
 4-cylinder
 liquid-cooled
 238.6 ci [3.9 L]
Bore/Stroke:3.875x5.06 inches [98 x 129 mm]
Power:65 hp [48.5 kW]
Gear Rated RPM:2200
Hydro Rated RPM:2400
Starter volts:12
Oil capacity:10 qts [9.5 L]
Oil change:100 h
Coolant capacity:15 qts [14.2 L]
Intake valve clearance:0.027 inches [0.686 mm] (hot)
Exhaust valve clearance:0.027 inches [0.686 mm] (hot)


Engine Detail:

 International Harvester C200
 gasoline
 4-cylinder
 liquid-cooled
 200.3 ci [3.3 L]
Bore/Stroke:3.8125x4.39 inches [97 x 112 mm]
Power:63 hp [47.0 kW]
Gear Rated RPM:2200
Hydro Rated RPM:2400
Starter volts:12
Oil capacity:7 qts [6.6 L]
Oil change:100 h
Sparkplug gap:0.023 inches [0.584 mm]
Point gap:0.020 inches [0.508 mm]
Intake valve clearance:0.027 inches [0.686 mm] (hot)
Exhaust valve clearance:0.027 inches [0.686 mm] (hot)
