Fiat 955C
|
|
| Production | |
| Manufacturer | Fiat |
| Agricultural Crawler tractor | |
| Fiat 955C Engine | |
| Fiat 4.6L 5-cyl diesel | |
| Fuel tank | 45 gal 170.3 L |
 Engine details ... | |
| Fiat 955C Transmission | |
| 8-speed gear | |
 Transmission details ... |
| Fiat 955C Power | |
| Engine | 88 hp 65.6 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | spur gear |
| Band brakes | |
| Two-post ROPS with canopy. | |
| Photos | |
| No photos of the Fiat 955C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2460 psi 169.6 bar |
| Rear valves | 2 to 4 |
| Pump flow | 11 gpm 41.6 lpm |
| Tractor hitch | |
| Rear Type | III/II OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2227 |
| Dimensions & Tracks | |
| Weight | 13051 lbs 5919 kg |
| 19.7-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 45 |
| Battery volts | 12 |
| References | |
 | |
| Compect Crawler Tractors 66 & 88 HP published in 1982, by Hesston |
