Valtra S274


No photo available
2014 - 2022
Model year
S Series
Row-Crop tractor
S233
Series:S274S294
Production
Manufacturer:Valtra (a part of AGCO)
Type:Row-Crop tractor
Valtra S274 Power
Engine:266 hp
198.4 kW
Valtra S274 Engine
AGCO Power 8.4L 6-cyl diesel
Fuel tank:166.4 gal
629.8 L
Exhaust fluid (DEF):15.9 gal
60.2 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:hydraulic wet disc
Cab:Cab standard with air-conditioning.
Transmission:continuously-variable transmission
Transmission details ...
Photos
No photos of the Valtra S274 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center load sensing
Rear valves:4 to 6
Front valves:0 to 2
Pump flow:54.2 gpm
205.1 lpm
Tractor hitch
Rear Type:IV/III
Rear lift:26455 lbs
11999 kg
Front lift:11023 lbs
5000 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540E/1000
 1000E/1000
Engine RPM:540E@1600
1000E@1600
1000@2030
Dimensions & Tires
Wheelbase:122.2 inches
310 cm
Weight:22708 lbs
10300 kg
Front tire:600/70R28
Rear tire:650/85R38
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Battery volts:12
