Fiat 446
| | 1983 - 1984 |
| Utility tractor |
|
| Production |
| Manufacturer: | Fiat
|
| Type: | Utility tractor
|
| Fiat 446 Power |
| Engine: | 50 hp
37.3 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Final drives: | planetary
|
| Differential lock: | mechanical rear
|
| Steering: | manual
|
| Steering: | power*Optional
|
| Brakes: | drum
|
| Cab: | Four-post ROPS.
|
| Transmissions: | 8-speed gear
|
| | 12-speed gear
|
 Transmission details ... |
| Photos |
| No photos of the Fiat 446 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Tractor hitch |
| Rear Type: | II/I
|
| Control: | position and draft control
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@2160
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 33
|
| Battery volts: | 12
|
