John Deere 25C


John Deere 25C tractor photo
2009 - 2015
Milenio C Series
Compact Utility tractor
Series:20C25C35C
Production
Manufacturer:John Deere
Type:Compact Utility tractor
John Deere 25C Power
Engine (gross):23.7 hp
17.7 kW
Engine (net):21.9 hp
16.3 kW
PTO (claimed):17.7 hp
13.2 kW
John Deere 25C Engine
Yanmar 1.1L 3-cyl diesel
Fuel tank:4.8 gal
18.2 L
Engine details ...
Mechanical
Steering:power
Cab:Two-post mid-mount folding ROPS.
Transmission:8-speed mechanical shuttle
Transmission details ...
Photos
No photos of the John Deere 25C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure:2176 psi
150.0 bar
Pump flow:3.7 gpm
14.0 lpm
Tractor hitch
Rear Type:IN
Rear lift (at 24"/610mm):551 lbs
249 kg
Power Take-off (PTO)
Rear RPM:540/1000
Dimensions & Tires
Weight:1962 lbs
889 kg
Front tire:6.5/80x12
Rear tire:8.25x16
Full dimensions and tires ...
