Tractors > John Deere > 35C

John Deere 35C



No photo available
2005 - 2015
Milenio C Series
Compact Utility tractor
Goldini built
Series map:
25C
35C
40C
17.7kw
24.6kw
28.3kw
Production
DistributorJohn Deere
ManufacturerGoldini
Compact Utility tractor
Built in Italy
John Deere 35C Engine
Lombardini 1.7L 3-cyl diesel
Fuel tank10.6 gal
40.1 L
Engine details ...
John Deere 35C Transmission
12-speed synchronized
Transmission details ...
John Deere 35C Power
Engine (gross)33 hp
24.6 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post mid-mount folding ROPS.
Photos
No photos of the John Deere 35C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2176 psi
150.0 bar
Pump flow8.7 gpm
32.9 lpm
Tractor hitch
Rear TypeI/IN
Rear lift (at ends)3086 lbs
1399 kg
Rear lift (at 24"/610mm)2205 lbs
1000 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Engine RPM540@2520
 1000@2620
Dimensions & Tires
Wheelbase63.6 inches
161 cm
Weight3351 lbs
1520 kg
Front tire200/70R16
Rear tire320/70R24
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps45
Battery volts12
References
35C references literature
Serie Milenio published in 2010, by John Deere
