Tractors > John Deere > 20C

John Deere 20C



John Deere 20C tractor photo
2009 - 2011
Milenio C Series
Compact Utility tractor
Series map:
20C
25C
13.8kw
17.7kw
Production
ManufacturerJohn Deere
Compact Utility tractor
John Deere 20C Engine
Yanmar 0.9L 3-cyl diesel
Fuel tank4.8 gal
18.2 L
Engine details ...
John Deere 20C Transmission
8-speed mechanical shuttle
Transmission details ...
John Deere 20C Power
Engine (gross)18.5 hp
13.8 kW
Engine (net)16.8 hp
12.5 kW
PTO (claimed)12 hp
8.9 kW
Mechanical
Power steering
Two-post mid-mount folding ROPS.
Photos
No photos of the John Deere 20C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2176 psi
150.0 bar
Pump flow3.7 gpm
14.0 lpm
Tractor hitch
Rear TypeIN
Rear lift (at 24"/610mm)551 lbs
249 kg
Power Take-off (PTO)
Rear PTO Type540/1000
Dimensions & Tires
Weight1962 lbs
889 kg
Front tire6.5/80x12
Rear tire8.25x16
Full dimensions and tires ...
References
20C references literature
20C/25C/3036E Standard Compact Utility Tractors published in 2009, by John Deere
Serie Milenio published in 2010, by John Deere
