Branson 3515H


Branson 3515H tractor photo
2016 -
15 Series
Compact Utility tractor
Series:3015H3515H4015H
Production
Manufacturer:Branson (a part of Kukje)
Type:Compact Utility tractor
Factory:South Korea
Variants
3515R:shuttle
3515H:hydrostatic
Branson 3515H Power
Engine:35 hp
26.1 kW
Branson 3515H Engine
Kukje 1.7L 3-cyl diesel
Fuel tank:7 gal
26.5 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power
Brakes:hydraulic wet disc
Cab:Two-post folding ROPS.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the Branson 3515H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:8.7 gpm
32.9 lpm
Steering flow:4.7 gpm
17.8 lpm
Tractor hitch
Rear Type:I
Control:position control
Rear lift (at ends):3306 lbs
1499 kg
Rear lift (at 24"/610mm):2420 lbs
1097 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/540E
Dimensions & Tires
Wheelbase:65.8 inches
167 cm
Weight:3014 lbs
1367 kg
Front tire:7x16
Rear tire:12.4x24
Full dimensions and tires ...
3515H Serial Numbers
Location:Serial number plate on the front right side of the main tractor frame, above the front axle.
photo of 3515H serial number

Electrical
Ground:negative
Battery volts:12
