CaseIH 956 XL

CaseIH 956 XL tractor photo
1985 - 1992
Utility tractor
Series next:CaseIH 1056 XL
Series back:CaseIH 856 XL






Production:

Manufacturer:CaseIH
Factory:Neuss, Germany


CaseIH 956 XL Engine:

   International Harvester 5.9L 6-cyl diesel
full engine details ...


Capacity:



3-Point Hitch:

Rear Type:II
Control:position and draft control
Rear lift:9532 lbs [4323 kg]
 11530 lbs [5230 kg] (optional)


Power Take-off (PTO):

Rear RPM:540/1000


Dimensions & Tires:

2WD Wheelbase:103.5 inches [262 cm]
4WD Wheelbase:102 inches [259 cm]
Weight:9458 to 10300 pounds
Front tire:7.50-20
Rear tire:16.9R38 (2WD)
full dimensions and tires ...


956 XL Serial Numbers:


- Serial numbers unknown -



CaseIH 956 XL Power:

Engine:95 hp [70.8 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:Cab standard with heat. Air-conditioning optional.


Hydraulics:

Pressure:2538 psi [175.0 bar]
Valves:up to 3
Pump flow:11.4 gpm [43.1 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:55


Battery:

Volts:12
