CaseIH 856 XL


CaseIH 856 XL tractor photo
1985 - 1987
Utility tractor
Series map:
844 XL
856 XL
956 XL
59.7kw
63.4kw
70.8kw
Production
ManufacturerCaseIH
Utility tractor
Built in Neuss, Germany
CaseIH 856 XL Engine
International Harvester 3.9L 4-cyl diesel
Engine details ...
CaseIH 856 XL Power
Engine85 hp
63.4 kW
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Cab standard with heat.
Photos
No photos of the CaseIH 856 XL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel28 gal
106.0 L
Front axle9.5 qts
9.0 L
Hydraulics
Pressure2465 psi
170.0 bar
Valvesup to 3
Pump flow6.6 gpm
25.0 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift8708 lbs
3949 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540/1000
Dimensions & Tires
2WD Wheelbase93.9 inches
238 cm
4WD Wheelbase92.4 inches
234 cm
Weight8465 to 9082 pounds
Front tire10.00x16
Rear tire16.9R34
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps33
Battery volts12
References
856 XL references literature
856XL - 956LX - 1056XL published by CaseIH
856XL - 956LX - 1056XL published in 1985, by CaseIH
