| | Production: |
| Manufacturer: | John Deere
|
| | Variants: |
| 5425: | utility
|
| 5425N: | narrow-profile
|
| | |
| John Deere 4.5L 4-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 19 gal [71.9 L]
|
| Hydraulic system: | 11.5 gal [43.5 L] (12-speed)
|
| | 12 gal [45.4 L] (24-speed)
|
| Front hubs: | 0.63 qts [0.6 L] (each)
|
| Front diff.: | 5.3 qts [5.0 L]
|
| | |
| Rear Type: | II/I
|
| Control: | top link draft sensing
|
| Rear lift (at 24"/610mm): | 3374 lbs [1530 kg]
|
| | |
| Rear PTO: | independent
|
| Clutch: | Electro-hydraulic
|
| Rear RPM: | 540/540E (1.375)
|
| | 540/1000 (1.375)
|
| Engine RPM: | 540E@1700
540@2400
1000@2400
|
| | |
| 2WD Wheelbase: | 86 inches [218 cm]
|
| 4WD Wheelbase: | 81.8 inches [207 cm]
|
| Weight: | 5483 to 5837 pounds
|
| full dimensions and tires ... | | | 5425N Serial Numbers: |
| Location: | Front left side of tractor frame, above front axle.
|
- Serial numbers unknown -
|
|
|
|
| | John Deere 5425N Power: |
| Engine (gross): | 81 hp [60.4 kW]
|
| PTO (claimed): | 65 hp [48.5 kW]
|
| | Mechanical: |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Two-post foldable ROPS. Cab optional.
|
| | Hydraulics: |
| Type: | open center
|
| Capacity: | 11.5 gal [43.5 L] (12-speed)
|
| | 12 gal [45.4 L] (24-speed)
|
| Pressure: | 2828 psi [195.0 bar]
|
| Rear valves: | 2 or 3
|
| Mid valves: | 2 (optional)
|
| Pump flow: | 18.4 gpm [69.6 lpm]
|
| Steering flow: | 24.9 gpm [94.2 lpm]
|
| Steering press.: | 1900 psi [131.0 bar]
|
| | Electrical: |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 70 (ROPS)
|
| | 90 (Cab)
|
| | 120 (optional)
|
| | Battery: |
| Number: | 1
|
| Cold-cranking amps: | 750
|
| Volts: | 12
|
| Group: | BCI 31
|
