Tractors > John Deere > 5325N

John Deere 5325N



John Deere 5325N tractor photo
2005 - 2008
5025 Series
Orchard/Vineyard tractor
Series map:
5325N
5425N
67.0hp
81.0hp
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
Variants
5325utility
5325Nnarrow-profile
John Deere 5325N Engine
John Deere 3.0L 5-cyl diesel
Engine details ...
John Deere 5325N Transmissions
12-speed partially synchonized
24-speed two-speed power shift
Transmission details ...
John Deere 5325N Power
Engine (gross)67 hp
50.0 kW
PTO (claimed)55 hp
41.0 kW
Mechanical
Two- or four-wheel drive
Steeringhydrostatic power
Hydraulic wet disc brakes
Two-post mid-mount folding ROPS. Cab optional.
Photos
No photos of the John Deere 5325N are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel19 gal
71.9 L
Hydraulic system11.5 gal (12-speed)
43.5 L
 12 gal (24-speed)
45.4 L
Front hubs0.63 qts (each)
0.6 L
Front diff.5.3 qts
5.0 L
Hydraulics
Typeopen center
Capacity11.5 gal (12-speed)
43.5 L
 12 gal (24-speed)
45.4 L
Pressure2828 psi
195.0 bar
Rear valves2 or 3
Mid valves2 (optional)
Pump flow13.5 gpm
51.1 lpm
Steering flow22.3 gpm
84.4 lpm
Steering press.1900 psi
131.0 bar
Tractor hitch
Rear TypeII/I
Controltop link draft sensing
Rear lift (at 24"/610mm)3374 lbs
1530 kg
Power Take-off (PTO)
Rear PTOindependent
ClutchElectro-hydraulic
Rear PTO Type540/540E (1.375)
 540/1000 (1.375)
Engine RPM540E@1700
 540@2400
 1000@2400
Dimensions & Tires
2WD Wheelbase81 inches
205 cm
4WD Wheelbase81.8 inches
207 cm
Weight4537 to 5445 pounds
Full dimensions and tires ...
5325N Serial Numbers
Location:Front left side of tractor frame, above front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps70 (ROPS)
 90 (Cab)
Battery CCA925
Battery volts12
Battery GroupBCI 31
References
5325N references literature
5025N Series Tractors published in 2005, by John Deere
Specialty Tractors published in 2008, by John Deere
