Tractors > Kubota > L3560

Kubota L3560

Kubota L3560 tractor photo
2013 -    L60 Series
Compact Utility tractor
Previous model:Kubota L3540
Series next:Kubota L4060






Production:

Manufacturer:Kubota


Variants:

L3560DT:4WD
L3560GST:4WD 12-speed
L3560HST:hydrostatic
L3560HSTC:hydro cab


Kubota L3560 Engine:

   Kubota 1.8L 3-cyl diesel
full engine details ...


Capacity:

Fuel:13.5 gal [51.1 L]


3-Point Hitch:

Rear Type:I
Control:position control, draft control optional
Rear lift (at 24"/610mm):2646 lbs [1200 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)
Mid PTO:optional
Mid RPM:2000


Dimensions & Tires:

Wheelbase:71.1 inches [180 cm]
Weight:3483 to 3880 pounds
Front tire:7.0-16
Rear tire:12.4-24
full dimensions and tires ...


L3560 Serial Numbers:


- Serial numbers unknown -



Kubota L3560 Power:

Engine (gross):37 hp [27.6 kW]
Engine (net):35 hp [26.1 kW]
PTO (claimed):29.5 hp [22.0 kW] (gear)
 28 hp [20.9 kW] (hydro)


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post foldable ROPS. Grand Cab with air-conditioning available with hydrostatic.


Hydraulics:

Gear Pump flow:8.3 gpm [31.4 lpm]
Hydro Pump flow:8.1 gpm [30.7 lpm]
Gear Total flow:13.2 gpm [50.0 lpm]
Hydro Total flow:12.8 gpm [48.4 lpm]
Gear Steering flow:4.9 gpm [18.5 lpm]
Hydro Steering flow:4.7 gpm [17.8 lpm]


Electrical:

Ground:negative
Charging system:alternator
ROPS Charging amps:40
Cab Charging amps:60


Battery:

Number:1
Volts:12
