Kubota L3560 Transmission


Kubota L3560 tractor photo
2013 -
L60 Series
Compact Utility tractor
L3540
Series:L3560L4060
Transmissions overview
8-speed synchronized shuttle
12-speed
hydrostatic
Transmission
Type:synchronized shuttle
Gears:8 forward and reverse
Clutch:mechanical dry disc
Speeds
L3560  synchronized shuttle speeds
Transmission
Transmission:Kubota Glide Shift
Gears:12 forward and 8 reverse
Clutch:hydraulic dry disc
Speeds
L3560 Glide Shift  speeds
Transmission
Transmission:HST Plus
Type:hydrostatic
Gears:infinite (3-range) forward and reverse
Hydrostatic transmission with three ranges plus Hydro Dual Speed Hi-Lo. The Dual Speed allows rapid switching between two speeds in range, either automatically or with a lever on the steering column.
Speeds
L3560 HST Plus hydrostatic speeds
