Kubota L3770
| | 2026 - |
| L70 Series | | Compact Utility tractor |
|
Series map:
L3770
L3970
37.0hp
39.0hp
| Production |
| Manufacturer | Kubota
|
| Compact Utility tractor |
| Original price was $31,829 in 2026 |
| Kubota L3770 Power |
| Engine (gross) | 37 hp
27.6 kW
|
| PTO (claimed) | 28 hp
20.9 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Photos |
| No photos of the Kubota L3770 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Rear valves | 3 OptOptional
|
| Pump flow | 8.03 gpm
30.4 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 3748 lbs
1700 kg
|
| Rear lift (at 24"/610mm) | 2646 lbs
1200 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2491
|
| Electrical |
| Ground | negative
|
| Battery CCA | 582
|
| Battery volts | 12
|
| References |
 |
| Grand L70 published in 2026, by Kubota |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on November 29, 2025 |
