CaseIH Steiger 420
| | 2014 - 2023 |
| Steiger 4WD Series | | Four-wheel Drive (4WD) tractor |
|
| Production |
| Manufacturer | CaseIH (a part of CNH)
|
| Four-wheel Drive (4WD) tractor |
| Built in Fargo, North Dakota, USA |
| Original price was $353,362 in 2015 |
| Variants |
| 420 | wheeled tractor
|
| 420RT | crawler tractor
|
| T9.480 | similar New Holland model
|
| CaseIH Steiger 420 Power |
| Engine | 420 hp
313.2 kW
|
| PTO (claimed) | 355 hp
264.7 kW
|
| Drawbar (tested) | 340.86 hp
254.2 kW
|
| PTO (tested) | 413.44 hp
308.3 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Steering | hydraulic articulated
|
| Brakes | hydraulic wet disc
|
| | engine brake OptOptional
|
| Trailer brakes | hydraulic OptOptional
|
| Surveyor Cab standard with air-conditioning. |
| Photos |
| No photos of the CaseIH Steiger 420 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | pressure flow compensated
|
| Valves | 4 to 8
|
| Pump flow | 42 gpm
159.0 lpm
|
| | 57 gpm*High Flow option
215.7 lpm
|
| | 113 gpm*TwinFlow option
427.7 lpm
|
| SCV flow | 35 gpm
132.5 lpm
|
| Tractor hitch |
| Rear Type | IVN
|
| | III *Optional.
|
| Rear lift (at 24"/610mm) | 20000 lbs
9072 kg
|
| Rear Arms | quick coupler
|
| Drawbar | Cat. 4
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1.75)
|
| Engine RPM | 1000@1998 (early)
|
| | 1000@1811 (late)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 200
|
| Batteries | 2
|
| Battery CCA | 1000
|
| Battery volts | 12
|
| References |
 |
| Steiger 370-620 Tractors published in 2014, by CaseIH |
