CaseIH Farmall 105U


CaseIH Farmall 105U tractor photo
2008 - 2016
Model year
Farmall U Series
Utility tractor
Series map:
Farmall 105U
Farmall 115U
105.0hp
115.0hp
Production
ManufacturerCaseIH
Utility tractor
Built in Italy
Original price was $89,167 in 2015
Variants
T5.105similar New Holland model
CaseIH Farmall 105U Engine
FPT 3.4L 4-cyl diesel
Fuel tank37 gal
140.0 L
Engine details ...
CaseIH Farmall 105U Transmissions
12-speed power shuttle
20-speed creeper power shuttle
24-speed two-speed power shift
Transmission details ...
CaseIH Farmall 105U Power
Engine (gross)105 hp
78.3 kW
PTO (claimed)91 hp
67.9 kW
Drawbar (tested)70.3 hp
52.4 kW
PTO (tested)99.3 hp
74.0 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Power steering
Hydraulic wet disc brakes
Cab with air-conditioning.
Photos
No photos of the CaseIH Farmall 105U are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Valves2 to 3
Pump flow16.1 gpm
60.9 lpm
 21.1 gpmOptOptional
79.9 lpm
Steering flow10 gpm
37.9 lpm
 11.4 gpmOptOptional
43.1 lpm
Tractor hitch
Rear TypeII
Controlelectronic draft control
Rear lift (at ends)adjustable lbs
0 kg
Rear lift (at 24"/610mm)6393 lbs
2899 kg
 11949 lbsOptOptional
5420 kg
DrawbarCat. II, swinging
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
 540E OptOptional
Dimensions & Tires
Wheelbase92.5 inches
234 cm
Weight9370 lbs
4250 kg
Front tire14.9R24
Rear tire18.4R34
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps120
Battery volts12
References
Farmall 105U references literature
Farmall U Series Utility Tractors published in 2013, by CaseIH
