New Holland Boomer 25

New Holland Boomer 25 tractor photo
2012 - 2014   Boomer Series
Sub-Compact Utility tractor
Previous model:New Holland Boomer 1025
Series back:New Holland Boomer 20






Production:

Manufacturer:New Holland


New Holland Boomer 25 Engine:

   Mitsubishi 1.3L 3-cyl diesel
full engine details ...


Capacity:

Fuel:6.6 gal [25.0 L]


Drawbar:

Drawbar:1-position fixed


3-Point Hitch:

Rear Type:I
Control:mechanical position control
Rear lift (at ends):1433 lbs [650 kg]
Rear lift (at 24"/610mm):1058 lbs [479 kg]
Rear Arms:fixed link ends


Power Take-off (PTO):

Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540
Mid PTO:independent
Mid RPM:2000


Dimensions & Tires:

Wheelbase:59 inches [149 cm]
Weight:1,702 lbs [772 kg]
Front tire:6-12
Rear tire:9.5-16
full dimensions and tires ...


New Holland Boomer 25 attachments:

 front-end loader
all Boomer 25 attachments ...


Boomer 25 Serial Numbers:


- Serial numbers unknown -



New Holland Boomer 25 Power:

Engine (gross):27 hp [20.1 kW]
PTO (claimed):19.9 hp [14.8 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Differential lock:Mechanical rear lock engaged with foot pedal. Limited slip front differential.
Steering:hydrostatic power
Brakes:mechanical wet disc
Cab:Two-post foldable ROPS.


Hydraulics:

Type:Open center, fixed displacement gear pump
Rear valves:1 (optional)
Pump flow:6 gpm [22.7 lpm]
Total flow:8.5 gpm [32.2 lpm]
Steering flow:2.5 gpm [9.5 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:50
Charging volts:12


Battery:

Number:1
Cold-cranking amps:560
Volts:12
Amp-hours:45
