New Holland Boomer 20

New Holland Boomer 20 tractor photo
2012 - 2014
Boomer Series
Sub-Compact Utility tractor
Boomer 1020
Series:Boomer 20Boomer 25
Manufacturer:New Holland
Type:Sub-Compact Utility tractor
New Holland Boomer 20 Power
Engine (gross):23 hp
17.2 kW
PTO (claimed):16.5 hp
12.3 kW
New Holland Boomer 20 Engine
Mitsubishi 1.1L 3-cyl diesel
Fuel tank:6.6 gal
25.0 L
Engine details ...
Chassis:4x4 MFWD 4WD
Differential lock:Mechanical rear lock engaged with foot pedal. Limited slip front differential.
Steering:hydrostatic power
Brakes:mechanical wet disc
Cab:Two-post foldable ROPS.
Transmission details ...
No photos of the New Holland Boomer 20 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Type:Open center, fixed displacement gear pump
Rear valves:1 (optional)
Pump flow:6 gpm
22.7 lpm
Total flow:8.5 gpm
32.2 lpm
Steering flow:2.5 gpm
9.5 lpm
Tractor hitch
Rear Type:I
Control:mechanical position control
Rear lift (at ends):1433 lbs
650 kg
Rear lift (at 24"/610mm):1058 lbs
479 kg
Rear Arms:fixed link ends
Drawbar:1-position fixed
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Mid PTO:independent
Mid RPM:2000
Dimensions & Tires
Wheelbase:59 inches
149 cm
Weight:1,702 lbs
772 kg
Front tire:6-12
Rear tire:9.5-16
Full dimensions and tires ...
Charging system:alternator
Charging amps:50
Charging volts:12
Battery CCA:560
Battery volts:12
Battery AH:45
