John Deere 6605
| | 1998 - 2005 |
| Utility tractor |
|
Series map:
6405
6605
7505
79.0kw
90.2kw
104.4kw
| Production |
| Manufacturer | John Deere
|
| Utility tractor |
| John Deere 6605 Power |
| Engine | 121 hp
90.2 kW
|
| PTO (claimed) | 103 hp
76.8 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | electro-hydraulic
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab optional. |
| Capacity |
| Fuel | 40.7 gal
154.0 L
|
| Hydraulic system | 15.1 gal
57.2 L
|
| Front axle | 7.1 qts
6.7 L
|
| Front hubs | 0.8 qts (each)
0.8 L
|
| Hydraulics |
| Type | closed-center flow-compensated
|
| Capacity | 15.1 gal
57.2 L
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 2 to 3
|
| Pump flow | 17.44 gpm
66.0 lpm
|
| | 26.42 gpmOptOptional
100.0 lpm
|
| SCV flow | 15.85 gpm
60.0 lpm
|
| Oil type |
|
| Tractor hitch |
| Rear Type | II
|
| Control | electronic lower link
|
| Rear lift (at ends) | 10,251 lbs
4649 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| ROPS Charging amps | 52
|
| Cab Charging amps | 75
|
| Battery volts | 12
|
| Battery AH | 150
|
