John Deere 6605 Transmission


John Deere 6605 tractor photo
1998 - 2005
Utility tractor
Series map:
6405
6605
7505
79.0kw
90.2kw
104.4kw
Transmission options
12-speed fully synchronized
16-speed partial power shift
Transmission
TransmissionJohn Deere SyncroPlus
Typefully synchronized
Gears12 forward and 4 reverse
Clutchhydraulic wet disc PermaClutch II
Oil capacity60.2 qts
57.0 L
Oil type
JD Hy-Gard
Three synchronized gears (1-3) in four synchronized ranges (A-D). Optional creeper range provides a total of 24 forward gears.
Speeds
With 18.4x34 R1 rear tires.
6605 SyncroPlus fully synchronized speeds
Transmission
TransmissionJohn Deere PowrQuad
Typepartial power shift
Gears16 forward and reverse
Clutchhydraulic wet disc PermaClutch II
Oil capacity60.2 qts
57.0 L
Oil type
JD Hy-Gard
Four power shift gears (1-4) in four synchronized ranges (A-D).
Speeds
With 18.4-34 R1 rear tires. Reverse speeds are 15% faster than forward speeds.
6605 PowrQuad partial power shift speeds
