John Deere 6615



John Deere 6615 tractor photo
2005 - 2010
Utility tractor
Series map:
6415
6615
7515
80.5kw
89.7kw
104.4kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Montenegro, Brazil
John Deere 6615 Engine
John Deere 6.8L 6-cyl diesel
Engine details ...
John Deere 6615 Transmissions
12-speed fully synchronized
16-speed partial power shift
Transmission details ...
John Deere 6615 Power
Engine120.3 hp
89.7 kW
PTO (claimed)103 hp
76.8 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic
Steeringhydrostatic power
Hydraulic wet disc brakes
Cab optional.
Photos
No photos of the John Deere 6615 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel45.4 gal
171.8 L
 81 gal (optional)
306.6 L
Hydraulic system16.4 gal
62.1 L
Front axle8.7 qts
8.2 L
Front hubs0.8 qts (each)
0.8 L
Hydraulics
Typeclosed center
Capacity16.4 gal
62.1 L
Pressure2900 psi
200.0 bar
Valves2 to 3
Pump flow17.44 gpm
66.0 lpm
 26.42 gpm (optional)
100.0 lpm
SCV flow15.85 gpm
60.0 lpm
 25.4 gpm (optional)
96.1 lpm
Oil type
JD Hy-Gard
Tractor hitch
Rear TypeII
Controlelectronic lower link
Rear lift (at ends)5,445 lbs
2469 kg
Rear lift (at 24"/610mm)4,762 lbs
2160 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540
 540/1000
Dimensions & Tires
Wheelbase104.3 inches
264 cm
Front tire14.9-26
Rear tire23.1-30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Battery volts12
Battery AH150
References
6615 references literature
6415, 6615 & 7515 Tractors published in 2004, by John Deere
