J.I. Case 2594
|
|
| Production | |
| Manufacturer: | J.I. Case |
| Type: | Row-Crop tractor |
| Factory: | Racine, Wisconsin, USA |
| J.I. Case 2594 Power | |
| Engine: | 217 hp 161.8 kW |
| Drawbar (claimed): | 161 hp 120.1 kW |
| PTO (claimed): | 180 hp 134.2 kW |
| Drawbar (tested): | 159.64 hp 119.0 kW |
| PTO (tested): | 182.07 hp 135.8 kW |
| J.I. Case 2594 Engine | |
| Case 8.3L 6-cyl diesel | |
 Engine details ... |
| Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | power |
| Brakes: | wet disc |
| Cab: | Silent Guardian cab with air-conditioning. |
| Transmissions: | 12-speed three-speed power shift |
| 24-speed four-speed power shift | |
 Transmission details ... | |
| Photos | |
| No photos of the J.I. Case 2594 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel: | 85 gal 321.7 L |
| 25 gal 94.6 L (optional auxiliary tank) | |
| Hydraulic system: | 32 gal 121.1 L |
| Hydraulics | |
| Type: | closed center |
| Capacity: | 32 gal 121.1 L |
| Pressure: | 2250 psi 155.1 bar |
| Valves: | 2 to 4 |
| Pump flow: | 27 gpm 102.2 lpm |
| Steering flow: | 8 gpm 30.3 lpm |
| Steering press.: | 2000 psi 137.9 bar |
| Tractor hitch | |
| Rear Type: | III |
| Rear lift (at 24"/610mm): | 7,750 lbs 3515 kg |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | hydraulic |
| Rear RPM: | 1000 |
| Dimensions & Tires | |
| Wheelbase: | 118 inches 299 cm |
| Weight: | 14875 to 16220 pounds |
| Front tire: | 11.00x16 |
| Rear tire: | 20.8x38 |
 Full dimensions and tires ... | |
| 2594 Serial Numbers | |
| Location: | Inside cab or on right-front frame |
| 1984: | 9931803 |
| 1985: | 9938951 |
| 1986: | 9941789 |
| 1987: | 9945455 |
| 1988: | 9948517 |
| Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 72 |
| 105*Optional | |
| Battery volts: | 12 |
