Kubota BX1850

Kubota BX1850 tractor photo
2006 - 2008
Compact Utility tractor
Previous model:Kubota BX1830
Next model:Kubota BX1860
Series next:Kubota BX2350






Production:

Manufacturer:Kubota
Original price (USD):$8,257 (2009)


Kubota BX1850 Engine:

   Kubota 0.7L 3-cyl diesel
full engine details ...


Capacity:

Fuel:6.6 gal [25.0 L]
Hydraulic system:3.1 gal [11.7 L]


3-Point Hitch:

Rear Type:I
Rear lift (at ends):992 lbs [449 kg]
Rear lift (at 24"/610mm):670 lbs [303 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540
Mid PTO:independent
Mid RPM:2500


Dimensions & Tires:

Wheelbase:52.8 inches [134 cm]
Weight:1,255 lbs [569 kg]
Front tire:16x7.5-8
Rear tire:24x12-12
full dimensions and tires ...


Kubota BX1850 attachments:

 front-end loader
all BX1850 attachments ...


BX1850 Serial Numbers:


- Serial numbers unknown -



Kubota BX1850 Power:

Engine:18 hp [13.4 kW]
PTO (claimed):13.7 hp [10.2 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:ROPS. Optional canopy.


Hydraulics:

Type:open center
Capacity:3.1 gal [11.7 L]
Total flow:6.3 gpm [23.8 lpm]


Electrical:

Charging system:alternator
Charging amps:40


Battery:

Number:1
Cold-cranking amps:435
Volts:12
