Massey Ferguson 5445

Massey Ferguson 5445 tractor photo
2004 - 2013   5400 Series
Model years
Utility tractor
Next model:Massey Ferguson 5445
Series next:Massey Ferguson 5455
Series back:Massey Ferguson 5435






Production:

Manufacturer:Massey Ferguson
Factory:Beauvais, France


Massey Ferguson 5445 Engine:

   Perkins 4.4L 4-cyl diesel
full engine details ...


Capacity:

Fuel:40 gal [151.4 L]
 53.2 gal [201.4 L] *Total capacity with optional tank.


3-Point Hitch:

Rear Type:II
Rear lift (at 24"/610mm):7,000 lbs [3175 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000
 540E/1000*Optional


Dimensions & Tires:

Wheelbase:97 inches [246 cm]
Weight:8630 to 9305 pounds
Front tire:10.00-16
Rear tire:480/70R38
full dimensions and tires ...


5445 Serial Numbers:


how to read serial numbers...



Massey Ferguson 5445 Power:

Engine:85 hp [63.4 kW]
Drawbar (claimed):61 hp [45.5 kW]
PTO (claimed):70 hp [52.2 kW]
Drawbar (tested):60.5 hp [45.1 kW]
PTO (tested):75.9 hp [56.6 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Steering:power
Brakes:independent hydraulic wet disc
Cab:ROPS, cab optional


Hydraulics:

Type:open center
 closed*Optional
Pressure:2684 psi [185.1 bar]
Valves:2 to 4
Total flow:15 gpm [56.8 lpm] (open)
 34.8 gpm [131.7 lpm] (combined flow)
 29 gpm [109.8 lpm] (closed)


Electrical:

Charging amps:80


Battery:

Cold-cranking amps:505
