Massey Ferguson 5455


Massey Ferguson 5455 tractor photo
2005 - 2013
Model year
5400 Series
Utility tractor
Series:544554555460
Production
Manufacturer:Massey Ferguson
Type:Utility tractor
Factory:Beauvais, France
Massey Ferguson 5455 Power
Engine:95 hp
70.8 kW
Drawbar (claimed):67 hp
50.0 kW
PTO (claimed):80 hp
59.7 kW
Drawbar (tested):66.8 hp
49.8 kW
PTO (tested):82.6 hp
61.6 kW
power test details ...
Massey Ferguson 5455 Engine
Perkins 4.4L 4-cyl diesel
Fuel tank:40 gal
151.4 L
 53.2 gal
201.4 L (with optional tank)
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:hydrostaic power
Brakes:independent hydraulic wet disc
Cab:ROPS, cab optional
Transmission:16-speed
Transmission details ...
Hydraulics
Type:open center
 closed optional
Pressure:2900 psi
200.0 bar
Valves:2 to 4
Total flow:15 gpm
56.8 lpm (open)
 34.8 gpm
131.7 lpm (combined flow)
 29 gpm
109.8 lpm (closed)
Tractor hitch
Rear Type:II
Rear lift (at 24"/610mm):7,000 lbs
3175 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
 540E/1000 (optional)
Dimensions & Tires
Wheelbase:97 inches
246 cm
Weight:8675 to 9305 pounds
Front tire:10.00-16
Rear tire:18.4R38
Full dimensions and tires ...
Electrical
Ground:negative
Charging amps:80
Battery CCA:505
Battery volts:12
