Massey Ferguson 5435


Massey Ferguson 5435 tractor photo
2004 - 2008
5400 Series
Utility tractor
Series map:
5435
5445
75.0hp
85.0hp
Production
ManufacturerMassey Ferguson
Utility tractor
Built in Beauvais, France
Massey Ferguson 5435 Engine
Perkins 4.4L 4-cyl diesel
Fuel tank40 gal
151.4 L
 53.2 gal (with optional tank)
201.4 L
Engine details ...
Massey Ferguson 5435 Power
Engine75 hp
55.9 kW
Drawbar (claimed)49 hp
36.5 kW
PTO (claimed)60 hp
44.7 kW
Drawbar (tested)48.5 hp
36.2 kW
PTO (tested)61.7 hp
46.0 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Independent hydraulic wet disc brakes
ROPS, cab optional
Photos
No photos of the Massey Ferguson 5435 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed OptOptional
Pressure2684 psi
185.1 bar
Valves2 to 4
Total flow15 gpm (open)
56.8 lpm
 34.8 gpm (combined flow)
131.7 lpm
 29 gpm (closed)
109.8 lpm
Tractor hitch
Rear TypeII
Rear lift (at 24"/610mm)7000 lbs
3175 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
 540E/1000 OptOptional
Dimensions & Tires
Wheelbase97 inches
246 cm
Weight8695 to 9335 pounds
Front tire7.50-16
Rear tire18.4R34
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps80
Battery CCA505
Battery volts12
References
5435 references literature
5400 Series published in 2006, by Massey Ferguson
