Massey Ferguson 5460


Massey Ferguson 5460 tractor photo
2005 - 2013
Model year
5400 Series
Utility tractor
Series map:
5455
5460
5465
95.0hp
105.0hp
109.0hp
Production
ManufacturerMassey Ferguson
Utility tractor
Built in Beauvais, France
Variants
5460SAlow-profile and narrow, special applications
Massey Ferguson 5460 Engine
Perkins 4.4L 4-cyl diesel
Fuel tank40 gal
151.4 L
 53.2 gal*With optional tank
201.4 L
Engine details ...
Massey Ferguson 5460 Power
Engine105 hp
78.3 kW
Drawbar (claimed)73 hp
54.4 kW
PTO (claimed)90 hp
67.1 kW
Drawbar (tested)73.0 hp
54.4 kW
PTO (tested)98.6 hp
73.5 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Independent hydraulic wet disc brakes
ROPS, cab optional
Photos
No photos of the Massey Ferguson 5460 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed center OptOptional
Pressure2900 psi
200.0 bar
Valves2 to 4
Total flow15 gpm (open)
56.8 lpm
 34.8 gpm (combined flow)
131.7 lpm
 29 gpm (closed)
109.8 lpm
Tractor hitch
Rear TypeII
Rear lift (at 24"/610mm)7,000 lbs
3175 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
 540E/1000 OptOptional
Dimensions & Tires
Wheelbase101.5 inches (2WD)
257 cm
 100.5 inches (4WD)
255 cm
Weight9170 to 9975 pounds
Front tire10.00-16
Rear tire18.4R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps80
Battery volts12
References
5460 references literature
5400 Series published in 2006, by Massey Ferguson
