John Deere 7930



John Deere 7930 tractor photo
2007 - 2011
7030 Series
Row-Crop tractor
Series map:
7830
7930
205.0hp
220.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
John Deere 7930 Engine
John Deere 6.8L 6-cyl diesel
Engine details ...
John Deere 7930 Transmissions
16-speed
20-speed
Transmission details ...
John Deere 7930 Power
Engine220 hp
164.1 kW
PTO (claimed)180 hp
134.2 kW
Drawbar (tested)165.51 hp
123.4 kW
PTO (tested)203.38 hp
151.7 kW
Performance test details ...
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
US model John Deere 7930.
John Deere 7930 photos...
Capacity
Fuel103 gal
389.9 L
 94 gal*Capacity with right-hand steps.
355.8 L
Hydraulic system28.5 gal
107.9 L
Hydraulics
Typeclosed center load-sensing
Capacity28.5 gal
107.9 L
Pressure2900 psi
200.0 bar
Valves2 to 7
SCV flow30 gpm
113.6 lpm
Total flow32 gpm
121.1 lpm
 45 gpmOptOptional
170.3 lpm
Tractor hitch
Rear TypeIII
Rear lift10,050 lbs
4558 kg
 14,000 lbsOptOptional
6350 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear PTO Type1000 (1.75)
 540/1000 (1.375)OptOptional
Engine RPM540@1950
 1000@1950
Dimensions & Tires
Wheelbase112.6 inches
286 cm
Weight17731 lbs
8042 kg
Front tire420/90R30
Rear tire480/80R46
Full dimensions and tires ...
7930 Serial Number Location
John Deere 7930 serial number location
Serial number plate on the right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Batteries2
Battery CCA925
Battery volts12
References
7930 references literature
7030 Series Tractors published in 2006, by John Deere
