International Harvester T-4
| | 1959 - 1964 |
| Agricultural Crawler tractor |
|
Series map:
T-4
T-5
36.2hp*
40.0hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | International Harvester
|
| Agricultural Crawler tractor |
| Factories | Melrose Park, Illinois, USA
|
| | Hamilton, Ontario, Canada
|
| International Harvester T-4 Power |
| Drawbar (claimed) | 27 hp
20.1 kW
|
| Belt (claimed) | 32.5 hp
24.2 kW
|
| Drawbar (tested) | 26.99 hp
20.1 kW
|
| PTO (tested) | 32.54 hp
24.3 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Final drives | bull gear
|
| Open operator station. |
| Tractor hitch |
| Rear Type | I OptOptional
|
| Power Take-off (PTO) |
| Rear PTO | live OptOptional
|
| Rear PTO Type | 1000 (1.375)
|
| Engine RPM | 980@2000
|
| References |
 |
| Farm Crawlers published in 1960, by International Harvester |
| Blue Ribbon Service Transmission and Final Drives (GSS-1255) |
