    John Deere 8110

    John Deere 8110 tractor photo
    1999 - 2002   8000 Ten Series
    Row-Crop tractor
    Previous model:John Deere 8100
    Next model:John Deere 8120
    Larger:John Deere 8210






    Production:

    Manufacturer:John Deere
    Factory:Waterloo, Iowa, USA


    Variants:

    8110:wheeled tractor
    8110T:crawler tractor


    John Deere 8110 Engine:

       John Deere 8.1L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:135 gal [511.0 L]


    3-Point Hitch:

    Rear Type:III, IIIN
    Rear lift:10,400 lbs [4717 kg]
     14,165 lbs [6425 kg] (optional)


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:1000
     540/1000 (optional)


    Dimensions & Tires:

    Wheelbase:116.4 inches [295 cm]
    Front tire:16.9R30
    Rear tire:18.4R46
    full dimensions and tires ...


    8110 Serial Numbers:

    Location:Rear of tractor

    - Serial numbers unknown -



    John Deere 8110 Power:

    PTO (claimed):165 hp [123.0 kW]


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Steering:hydrostatic power


    Hydraulics:

    Type:closed center PFC
    Valves:3 to 5
    Pump flow:30 gpm [113.6 lpm]


    Electrical:

    Charging amps:140


    Battery:

    Number:2
    Cold-cranking amps:1,850
    Volts:12
