| Transmissions overview |
| 8-speed unsynchronized gear |
| 16-speed two-speed power shift |
| 12-speed |
| 24-speed |
| 16-speed |
| Transmission |
| Transmission | EconoShift
|
| Type | unsynchronized gear
|
| Gears | 8 forward and 2 reverse
|
| Four gears, plus reverse, in two ranges. Tractor must be stopped, and clutch used, before shifting gear or range. Optional creeper range. |
| Speeds |
| With 16.9-34 rear tires. |
|
| Transmission |
| Transmission | Econo Dual Command
|
| Type | two-speed power shift
|
| Gears | 16 forward and 4 reverse
|
| Same as EconoShift, with an additional under-speed power shift button on the dashboard. The direct/underspeed ranges may be shifted on the move without the clutch. Four gears, plus reverse, in two ranges. Tractor must be stopped, and clutch used, before shifting gear or range. Optional creeper range. |
| Speeds |
| With 16.9-34 rear tires. |
|
| Transmission |
| Transmission | Synchro Command
|
| Gears | 12 forward and reverse
|
| Oil capacity | 60 qts
56.8 L
|
| Four gears provided in three ranges, plus a shuttle lever. Tractor may be shifted on the move, using the clutch, between gears, high or medium range, and forward-reverse shuttle. Tractor must be stopped to enter low range. |
| Speeds |
| 16.9-38 rear tires. |
|
| Transmission |
| Transmission | Synchro Dual Command
|
| Gears | 24 forward and reverse
|
| Oil capacity | 60 qts
56.8 L
|
| Same as Synchro Command, with an additional under-speed power shift button on the gear lever. The direct/underspeed ranges may be shifted on the move without the clutch. A 'dump button' on the shuttle lever can be used for clutchless shifting between forward and reverse. |
| Speeds |
| 16.9-38 rear tires. |
|
| Transmission |
| Transmission | ElectroShift
|
| Gears | 16 forward and reverse
|
| Oil capacity | 64 qts
60.6 L
|
| Transmission |
| Transmission | ElectroShift - creeper
|
| Gears | 24 forward and reverse
|
| Additional range of creeper gears can be selected using the clutch with the range in low. Creeper engaged by a toggle switch. |
