Allis Chalmers HD10
|
|
| Production | |
| Manufacturer | Allis Chalmers |
| Agricultural Crawler tractor | |
| Built in Springfield, Illinois, USA | |
| Total built | 8,750 |
| Allis Chalmers HD10 Engine | |
| General Motors 4.7L 4-cyl diesel | |
| Fuel tank | 44 gal 166.5 L |
 Engine details ... | |
| Allis Chalmers HD10 Power | |
| Drawbar (claimed) | 65 hp 48.5 kW |
| Belt (claimed) | 86 hp 64.1 kW |
| Drawbar (tested) | 82.19 hp 61.3 kW |
| Belt (tested) | 98.5 hp 73.5 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | crawler |
| Open operator station. | |
| Dimensions & Tracks | |
| Weight | 20380 to 21455 pounds |
| 18-inch tracks | |
 Full dimensions and tracks ... | |
| HD10 Serial Numbers | |
| Location: | Rear of transmission case or plate near instrument panel. |
| 1940 | 2 |
| 1941 | 642 |
| 1942 | 1446 |
| 1946 | 5964 |
| 1947 | 6463 |
| 1948 | 7602 |
| 1949 | 8676 |
| 1950 | 9631 |
| Final | 10198 |
FAQ: How to read a serial number table. | |
| References | |
 | |
| It's a Modern Diesel - built for you published in 1941, by Allis Chalmers | |
| Build a Better Farm published in 1940, by Allis Chalmers |
