Deutz-Fahr Intrac 2003


Deutz-Fahr Intrac 2003 tractor photo
1974 - 1979
Intrac 2000 Series
Tool Carrier tractor
Series:Intrac 2002Intrac 2003Intrac 2004
Production
Manufacturer:Deutz-Fahr
Type:Tool Carrier tractor
Deutz-Fahr Intrac 2003 Power
Engine:59 hp
44.0 kW
Deutz-Fahr Intrac 2003 Engine
Deutz 3.8L 4-cyl diesel
Fuel tank:23 gal
87.1 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
2WD Steering:manual
4WD Steering:power
Cab:Cab standard.
Transmissions:8-speed
 8-speed synchronized
 12-speed creeper
Transmission details ...
Photos
No photos of the Deutz-Fahr Intrac 2003 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:10.5 gpm
39.7 lpm
Tractor hitch
Rear Type:II/I
Rear lift:5291 lbs
2399 kg
Front Hitch:I
Front lift:2205 lbs
1000 kg
Power Take-off (PTO)
Rear RPM:540/1000 (1.375)
Engine RPM:540@1890
1000@1875
Front RPM:1000 (1.375)
Engine RPM:1000@1875
Dimensions & Tires
4WD Wheelbase:86.6 inches
219 cm
Weight:6240 to 7606 pounds
Front tire:7.50-18
4WD Rear tire:12.4-32
Full dimensions and tires ...
