Tractors > Zetor > Proxima 8421

Zetor Proxima 8421

No photo available
2004 - 2007   Proxima Series
Series next:Zetor 8441
Series back:Zetor 7441






Production:

Manufacturer:Zetor
Factory:Brno, Czechoslovakia


Variants:

8421:2WD
8441:4WD


Zetor 8421 Engine:

   Zetor 4.2L 4-cyl diesel
full engine details ...


Capacity:

ROPS Fuel:20 gal [75.7 L]
Cab Fuel:32 gal [121.1 L]


3-Point Hitch:

Rear Type:II/I
Control:position and draft control
Rear lift:6830 lbs [3098 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:90 inches [228 cm]
Weight:7440 lbs [3374 kg]
Front tire:9.00-16
Rear tire:16.9-34
full dimensions and tires ...


Zetor 8421 attachments:

 front-end loader
all 8421 attachments ...


8421 Serial Numbers:


- Serial numbers unknown -



Zetor 8421 Power:

Engine:84 hp [62.6 kW]
PTO (claimed):78 hp [58.2 kW]


Mechanical:

Chassis:4x2 2WD
Cab:Two-post folding ROPS. Cab optional with air-conditioning.


Hydraulics:

Type:open center
Pressure:2900 psi [200.0 bar]
Valves:3
Pump flow:14 gpm [53.0 lpm]
Total flow:18 gpm [68.1 lpm]


Battery:

Number:1
Volts:12
