Zetor Proxima 7421
| | 2004 - 2007 |
| Proxima Series |
|
| Production |
| Manufacturer: | Zetor
|
| Factory: | Brno, Czechoslovakia
|
| Zetor 7421 Power |
| Engine: | 75 hp
55.9 kW
|
| PTO (claimed): | 70 hp
52.2 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Cab: | Two-post folding ROPS. Cab optional with air-conditioning.
|
| Transmissions: | 10-speed syncromesh
|
| | 12-speed mechanical shuttle
|
 Transmission details ... |
| Photos |
| No photos of the Zetor 7421 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2900 psi
200.0 bar
|
| Valves: | 3
|
| Pump flow: | 14 gpm
53.0 lpm
|
| Total flow: | 18 gpm
68.1 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Control: | position and draft control
|
| Rear lift: | 6830 lbs
3098 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
