Zetor 12245

Zetor 12245 tractor photo
1990 - 1997
Row-Crop tractor
Series next:Zetor 14245
Series back:Zetor 12211






Production:

Manufacturer:Zetor
Factory:Brno, Czechoslovakia
Original price (USD)
   $35,000 (1992 )


Variants:

12211:2WD
12245:4WD


Zetor 12245 Engine:

   Zetor 6.8L 6-cyl diesel
full engine details ...


Capacity:

Fuel:34.3 gal [129.8 L]


3-Point Hitch:

Rear Type:II
Rear lift:8650 lbs [3923 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:106.1 inches [269 cm]
Weight:10626 to 12059 pounds
Front tire:14.9x24
Rear tire:18.4x38
full dimensions and tires ...


12245 Serial Numbers:


- Serial numbers unknown -



Zetor 12245 Power:

Engine:120 hp [89.5 kW]
PTO (claimed):105 hp [78.3 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:power
Brakes:hydraulic dry disc
Trailer brakes:pneumatic
 hydraulic*Optional
Cab:Cab standard with heater.


Hydraulics:

Type:open center
Pressure:2800 psi [193.1 bar]
Valves:2
Pump flow:12.4 gpm [46.9 lpm]


Electrical:

Charging system:alternator
Charging amps:55
