CaseIH STX425
|
|
| Production | |
| Manufacturer | CaseIH |
| Four-wheel Drive (4WD) tractor | |
| Built in Fargo, North Dakota, USA | |
| CaseIH STX425 Engine | |
| Cummins 14.9L 6-cyl diesel | |
| Fuel tank | 300 gal 1135.5 L |
 Engine details ... | |
| CaseIH STX425 Transmissions | |
| 16-speed full power shift | |
| 24-speed fully synchronized | |
 Transmission details ... |
| CaseIH STX425 Power | |
| Engine | 425 hp 316.9 kW |
| Drawbar (claimed) | 345 hp 257.3 kW |
| PTO (claimed) | 370 hp 275.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary (standard) |
| compound planetary (HD/scraper) | |
| Steering | hydrostatic power |
| Integrated hydraulic wet disc brakes | |
| Surveyor Cab standard. | |
| Photos | |
| No photos of the CaseIH STX425 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | pressure flow compensated (PFC) |
| Rear valves | 4 to 7 |
| SCV flow | 35 gpm 132.5 lpm |
| Total flow | 40 gpm 151.4 lpm |
| 55 gpmOptOptional 208.2 lpm | |
| Tractor hitch | |
| Rear Type | IVN/III |
| Rear lift (at 24"/610mm) | 19500 lbs 8845 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Rear PTO Type | 1000 (1.75) |
| Dimensions & Tires | |
| Wheelbase | 154 inches 391 cm |
 Full dimensions and tires ... | |
| STX425 Serial Numbers | |
| 2002 | JEE0099501 |
| 2003 | JEE0102001 |
| 2004 | JEE0104001 |
| 2005 | JEE0105701 |
| 2006 | JEE0108501 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| STX Series Steiger Tractors published in 2002, by CaseIH* | |
| *Publication contains known errors. |
