    CaseIH MXU110

    CaseIH MXU110 tractor photo
    2004 - 2006   MXU Maxxum Series
    Utility tractor
    Larger:CaseIH MXU115
    Smaller:CaseIH MXU100



    Factory:Basildon, England
    Original price (USD):$43,150 (2005)

    CaseIH MXU110 Engine:

       CNH 4.5L 4-cyl diesel
    full engine details ...


    Fuel:46.7 gal [176.8 L]

    3-Point Hitch:

    Rear Type:II (ROPS)
     II/IIIN (cab)
    Control:mechanical lower link (ROPS)
     electronic draft control (cab)
    Rear lift:9,285 lbs [4211 kg]
     12,185 lbs [5527 kg] (with cab)

    Power Take-off (PTO):

    Rear PTO:independent
    Clutch:electro-hydraulic wet plates
    Rear RPMs:540/1000
    Engine RPMs:540@1969

    Dimensions & Tires:

    Wheelbase:93.3 inches [236 cm] (2WD)
     94.9 inches [241 cm] (4WD)
    Weight:9568 to 11440 pounds
    Front tire:7.50x16
    Rear tire:16.9R38 (2WD)
    full dimensions and tires ...

    CaseIH MXU110 attachments:

     front-end loader
    all MXU110 attachments ...

    MXU110 Serial Numbers:

    - Serial numbers unknown -

    CaseIH MXU110 Power:

    Engine (gross):115 hp [85.8 kW]
    PTO (claimed):95 hp [70.8 kW]
    Drawbar (tested):86.4 hp [64.4 kW]
    PTO (tested):114.7 hp [85.5 kW]
    power test details ...


    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Final drives:planetary inboard
    Differential lock:electro-hydraulic rear standard
     front optional
    Steering:hydrostatic pwoer
    Brakes:differential hydraulic wet disc
    Cab:Two-post ROPS. Cab optional.


    Type:pressure-flow compensated (PFC) optional
    Pressure:2974 psi [205.1 bar]
     3118 psi [215.0 bar] (PFC)
    Rear valves:2 to 4
    Pump flow:19.8 gpm [74.9 lpm]
     26.5 gpm [100.3 lpm] (PFC)
    Total flow:30.3 gpm [114.7 lpm]
     37 gpm [140.0 lpm] (PFC)


    Charging system:alternator
    Charging amps:70 (ROPS)
     120 (cab)


    Cold-cranking amps:1300
