John Deere 8220T


John Deere 8220T tractor photo
2002 - 2005
8020 Series
Agricultural Crawler tractor
Series map:
8120T
8220T
8320T
208.0hp
233.0hp
263.0hp
Production
ManufacturerJohn Deere
Agricultural Crawler tractor
Built in Waterloo, Iowa, USA
Variants
8220wheeled tractor
8220Tcrawler
John Deere 8220T Engine
John Deere 8.1L 6-cyl diesel
Engine details ...
John Deere 8220T Power
Engine (gross)233 hp
173.7 kW
Engine (net)225 hp
167.8 kW
Engine (max)256 hp
190.9 kW
PTO (claimed)190 hp
141.7 kW
Drawbar (tested)158.81 hp
118.4 kW
PTO (tested)216.32 hp
161.3 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringelectro-hydraulic power
Hydraulic wet disc brakes
Cab standard.
Photos
No photos of the John Deere 8220T are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel130 gal
492.1 L
Hydraulic system65 gal
246.0 L
Hydraulics
Typeclosed center pressure flow compensated (PFC)
Capacity65 gal
246.0 L
Pressure2900 psi
200.0 bar
Valves5
Pump flow30 gpm
113.6 lpm
Total flow33.5 gpm
126.8 lpm
 42.5 gpm (optional)
160.9 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift15,180 lbs
6885 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM1000 (1-3/4)
Dimensions & Tracks
Wheelbase89 inches
226 cm
 120 inches (wide track opt)
304 cm
Weight25,950 lbs
11770 kg
24-inch tracks
Full dimensions and tracks ...
8220T Serial Numbers
Location:Rear of tractor
Electrical
Groundnegative
Charging systemalternator
Charging amps150
Batteries2
Battery CCA925
Battery volts12
References
8220T references literature
8020T/9020T Series published in 2003, by John Deere
