Tractors > John Deere > 9320T

John Deere 9320T - tests

No photo available
2002 - 2007   9020 Series
Agricultural Crawler tractor
Previous model:John Deere 9300T
Series next:John Deere 9420T
more John Deere 9320T specifications...






OCED Tractor Test 1804:

Nebraska summary:370
9320T fuel use from test 370
Test Date:April 5 - May 31, 2002
Type:Diesel 18-speed crawler
PTO power (max):389.14 hp [290.2 kW]
PTO fuel use (max):22.1 gal/hour [83.6 l/hour]
PTO power (rated engine speed):389.14 hp [290.2 kW]
PTO fuel use (engine speed):23.0 gal/hour [87.1 l/hour]
PTO power (rated PTO speed):358.95 hp [267.7 kW]
PTO fuel use (PTO speed):20.3 gal/hour [76.8 l/hour]
Drawbar power (max):305.74 hp [228.0 kW]
Drawbar fuel use (max):19.7 gal/hour [74.6 l/hour]
Drawbar pull (max):41,473 lbs [18812 kg]
Max pull gear:1
Test report:PDF file
