    Massey Ferguson 1135

    Massey Ferguson 1135 tractor photo  I&T Manual: Massey 65, 85, 88, 90, 1100, 1130, 1150, 1105, 1135, 1155, 1080, 1085
    I&T Shop Manual
    1973 - 1978






    Production:

    Manufacturer:Massey Ferguson
    Original price (USD):$31,500 (1978)


    Massey Ferguson 1135 Engine:

       Perkins 5.8L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:55 gal [208.2 L]
    Hydraulic system:21.9 gal [82.9 L]


    3-Point Hitch:

    Rear Type:II
    Rear lift:5,350 lbs [2426 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540 (1.375)
     1000 (1.375)
    Engine RPMs:1000@2000


    Dimensions & Tires:

    Wheelbase:109.1 inches [277 cm]
    Weight:11000 to 18900 pounds
    Front tire:11.00-16
    Rear tire:18.4-38
    full dimensions and tires ...


    1135 Serial Numbers:

    Location:Forward on instrument panel on left side.
    1972: 9B36563
    1973: 9B36841
    1974: 9B42685
    1975: 9B50494
    1976: 9B58735
    1977: 9B66276
    1978: 9B74241
    1979: 9B76058

    how to read serial numbers...



    Massey Ferguson 1135 Power:

    Drawbar (claimed):102 hp [76.1 kW]
    PTO (claimed):121 hp [90.2 kW]
    Drawbar (tested):102.44 hp [76.4 kW]
    PTO (tested):120.84 hp [90.1 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
    Steering:hydrostatic power
    Brakes:hydraulic disc
    Cab:Open operator station. Cab optional with heat and air-conditioning available.


    Hydraulics:

    Capacity:21.9 gal [82.9 L]
    Pressure:2034 psi [140.2 bar]
    Valves:1
    Pump flow:20 gpm [75.7 lpm]


    Electrical:

    Charging system:alternator


    Battery:

    Number:2
    Volts:12
    Amp-hours:96
