    International Harvester 5088

    International Harvester 5088 tractor photo  I&T Manual: IH 5088, 5288, 5488
    I&T Shop Manual
    1981 - 1985   50 Series
    Row-Crop tractor
    Larger:International Harvester 5288






    Production:

    Manufacturer:International Harvester
    Factory:Rock Island, Illinois, USA
    Total built:8,176
    Original price (USD):$54,300 (1985)


    International Harvester 5088 Engine:

       International Harvester 7.1L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:70 gal [264.9 L]
    Hydraulic system:43.5 gal [164.6 L]


    3-Point Hitch:

    Rear Type:3
    Rear lift:6,990 lbs [3170 kg]
     8,280 lbs [3755 kg] (optional)


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540/1000


    Dimensions & Tires:

    Wheelbase:111.6 inches [283 cm]
    Weight:13765 to 16010 pounds
    Front tire:10.00-16
    Rear tire:18.4-38
    full dimensions and tires ...


    5088 Serial Numbers:

    Location:Right side of tractor frame
    1981: 501
    1982: 3551
    1983: 6015
    1984: 7307
    1985: 8623

    how to read serial numbers...



    International Harvester 5088 Power:

    Drawbar (claimed):119 hp [88.7 kW]
    PTO (claimed):135 hp [100.7 kW]
    Drawbar (tested):116.19 hp [86.6 kW]
    PTO (tested):136.12 hp [101.5 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD optional
    Steering:hydrostatic power
    Brakes:wet disc
    Cab:Cab standard with heat and A/C. Optional burgundy or western interior finish.


    Hydraulics:

    Type:closed center
    Capacity:43.5 gal [164.6 L]
    Valves:2
    Pump flow:25 gpm [94.6 lpm]
     40 gpm [151.4 lpm] (optional)
    Total flow:67 gpm [253.6 lpm]
     82 gpm [310.4 lpm] (optional)
    Steering flow:12 gpm [45.4 lpm]
