Tractors > International Harvester > 5288

International Harvester 5288



International Harvester 5288 tractor photo
1981 - 1985
50 Series
Row-Crop tractor
Series map:
5088
5288
5488
150.0hp*
177.8hp*
205.6hp*
*Estimated engine power for comparison only.
Production
ManufacturerInternational Harvester
Row-Crop tractor
Built in Rock Island, Illinois, USA
Total built5,905
Original price was $60,000 in 1985
International Harvester 5288 Engine
International Harvester 7.6L 6-cyl diesel
Engine details ...
International Harvester 5288 Transmission
18-speed partial power shift
Transmission details ...
International Harvester 5288 Power
Drawbar (claimed)141 hp
105.1 kW
PTO (claimed)160 hp
119.3 kW
Drawbar (tested)137.63 hp
102.6 kW
PTO (tested)162.6 hp
121.3 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Power steering
Hydraulic wet disc brakes
Cab standard with heat and air-conditioning. Optional burgundy or western interior finish.
Photos
International 5288, front-left view
International Harvester 5288 photos...
Capacity
Fuel87 gal
329.3 L
Hydraulic system43.5 gal
164.6 L
Hydraulics
Typeclosed center
Capacity43.5 gal
164.6 L
Valves2
Pump flow25 gpm
94.6 lpm
 40 gpmOptOptional
151.4 lpm
Total flow67 gpm
253.6 lpm
 82 gpmOptOptional
310.4 lpm
Steering flow12 gpm
45.4 lpm
Tractor hitch
Rear TypeIII
Rear lift8076 lbs
3663 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000
Dimensions & Tires
Wheelbase111.6 inches
283 cm
Weight14610 to 17055 pounds
Front tire14L-16.1
Rear tire20.8-38
Full dimensions and tires ...
5288 Serial Number Location
International Harvester 5288 serial number location
Right side of tractor frame
5288 Serial Numbers
1981501
19822292
19834086
19845054
19856334

FAQ: How to read a serial number table.
Electrical
Groundnegative
Battery volts12
References
5288 references literature
Buyer's Guide 1982 published by International Harvester
The New Number One! - Tractors 135/160/185 HP published in 1981, by International Harvester
50 Series Tractors published in 1985, by International Harvester
