Ford 9000
| | 1970 - 1972 |
| Row-Crop tractor |
|
Series map:
8000
9000
115.5hp
145.0hp
| Production |
| Manufacturer | Ford
|
| Row-Crop tractor |
| Built in Highland Park, Michigan, USA |
| Original price | $11,600
|
| Variants |
| 9100 | all-purpose
|
| 9200 | row-crop
|
| Ford 9000 Power |
| Engine | 145 hp
108.1 kW
|
| PTO (claimed) | 130 hp
96.9 kW
|
| Drawbar (tested) | 110.35 hp
82.3 kW
|
| PTO (tested) | 131.22 hp
97.9 kW
|
 Performance test details ... |
| Mechanical |
| Two-wheel drive |
| Final drives | planetary
|
| Power steering |
| Differential hydraulic wet disc brakes |
| Open operator station. Cab optional |
| Capacity |
| Fuel | 43 gal
162.8 L
|
| Hydraulic system | 16 gal
60.6 L
|
| | 17.3 gal (Dual Power)
65.5 L
|
| Steering | 3 qts
2.8 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 16 gal
60.6 L
|
| | 17.3 gal (Dual Power)
65.5 L
|
| Pressure | 2500 psi
172.4 bar
|
| Pump flow | 16 gpm
60.6 lpm
|
| Steering flow | 4.2 gpm
15.9 lpm
|
| Steering cap. | 3 qts
2.8 L
|
| Steering press. | 1500 psi
103.4 bar
|
| Tractor hitch |
| Rear Type | III/II
|
| Control | position control and lower-link draft sensing
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 55
|
| Battery volts | 12
|
| Battery AH | 128
|
| References |
 |
| Buyer's Guide '73 published in 1973, by Ford |
| 8000, 8600, 9000 and 9600 Repair Time Schedule (SE 3410) published in 1973 |
| 9000 Operator's Manual (SE 3259) published in 1969 |
| Ford Tractor Sales Handbook published in 1968 |
