Ford 1600
| | 1976 - 1979 |
| Compact Utility tractor | | Shibaura built |
|
Series map:
1600
25.6hp*
*Estimated engine power for comparison only.
| Production |
| Distributor | Ford
|
| Manufacturer | Shibaura
|
| Compact Utility tractor |
| Built in Japan |
| Original price was $5,425 in 1979 |
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | mechanical rear
|
| Manual steering |
| Differential mechanical expanding shoe brakes |
| Open operator station. Two-post fixed ROPS optional. |
| Capacity |
| Fuel | 5.8 gal
22.0 L
|
| Hydraulic system | 2.6 gal
9.8 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 2.6 gal
9.8 L
|
| Pressure | 1422 psi
98.0 bar
|
| Total flow | 4.2 gpm
15.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 1700 lbs
771 kg
|
| Power Take-off (PTO) |
| Rear PTO | transmission
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@1955
|
| 1600 Serial Number Location |
 |
| On the tractor's clutch housing, left side. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 10
|
| Battery volts | 12
|
| Battery AH | 70
|
| References |
 |
| 1600 Tractor Four-Wheel Drive Option published in 1978, by Ford |
| Operator's Manual 1600 (SE 3551) published in 1976 |
| Ford 1600 published in 1978 |
| Page information |
 |
| Copyright 2023 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on September 9, 2023 |
