Ford 1000
|
|
| Production | |
| Distributor | Ford |
| Manufacturer | Shibaura |
| Compact Utility tractor | |
| Built in Japan | |
| The Ford 1000 is similar to Shibaura 1500 | |
| Ford 1000 Engine | |
| Shibaura 1.3L 2-cyl diesel | |
 Engine details ... |
| Ford 1000 Transmission | |
| 9-speed gear | |
 Transmission details ... |
| Ford 1000 Power | |
| Engine | 25 hp 18.6 kW |
| PTO (claimed) | 23 hp 17.2 kW |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear |
| Open operator station. Optional two-post ROPS. | |
| Photos | |
 | |
 Ford 1000 photos... | |
| Capacity | |
| Fuel | 5.8 gal 22.0 L |
| Hydraulic system | 2.1 gal 7.9 L |
| Hydraulics | |
| Type | open cetner |
| Capacity | 2.1 gal 7.9 L |
| Pump flow | 4.2 gpm 15.9 lpm |
| Tractor hitch | |
| Rear Type | I |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| Rear RPM | 540 |
| Dimensions & Tires | |
| Wheelbase | 62.6 inches 159 cm |
| Weight | 2300 lbs 1043 kg |
| Front tire | 5.00-15 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| 1000 Serial Numbers | |
| Location: | Serial number plate on the left side of the clutch housing. |
| 1973 | U100001 |
| 1974 | U100821 |
| 1975 | U102021 |
| 1976 | U102771 |
| 1978 | U108449 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 10 |
| Battery volts | 12 |
| References | |
 | |
| Ford Shop Manual by Peter Letourneau | |
| Ford 1000 published in 1973 | |
| Ford 1000 - The Baby Brute published in 1973 |
